Buy Pancake Jacks Plain Ram in UAE – Low-Height Lifting Made Easy

Looking for a reliable lifting tool that fits where others can’t? Pancake Jacks Plain Ram UAE are the go-to solution when space is tight but the load is heavy. With a height as low as 38 mm and a lifting force that surprises many, these flat hydraulic jacks UAE are popular in maintenance pits, shipyards, construction bases, and machinery setups across the UAE.

Unlike standard cylinders, these low height jacks have a wider footprint for better stability and load distribution, even on uneven surfaces. The spring return pancake jack design allows quick retraction, cutting downtime between lifts. Built with industrial-grade steel and corrosion-resistant plating, they’re made to handle the heat, sand, and load cycles common in Middle Eastern industrial zones.

Buyers often don’t realize how critical these compact hydraulic jacks UAE are in synchronised lifting projects and bridge maintenance. They’re compact and carry the muscle of full-size alternatives. Popular models range from 10 to 150 tons, with stroke lengths that can go up to 50 mm. If you’re comparing with brands like Enerpac UAE or SPX Flow UAE, this is where power meets precision.

What Are Pancake Jacks with Plain Ram?

A Plain Ram Pancake Jack UAE is a compact hydraulic tool built for low-clearance lifting jobs. With its flat body and solid ram design, this hydraulic flat jack is made for situations where traditional jacks simply won’t fit. It has no threads or attachments on the ram, making it ideal for straight vertical lifts where minimal stroke and high load capacity are required.

These flat hydraulic jacks are commonly used in shipbuilding, mining maintenance, power plants, bridge repairs, and confined industrial setups. They’re a favorite for lifting heavy equipment during shutdowns or tight-schedule projects. Because they are low-profile lifting jacks UAE, they can slide under loads with just a few centimeters of ground clearance.

A plain ram spring return jack retracts automatically once pressure is released, which is helpful when lifting in difficult spots. Models like the Enerpac CULP and Hi-Force HPS Series offer tonnage up to 200T with strokes as short as 6mm.

Hydraulic Hand Pumps Steel

Technical Specification

Capacity 10 - 200 ton / Stroke 10 mm / Max. Working Pressure 700 bar
Capacity
(ton)
Capacity
(kN)
Stroke
(mm)
Model Effective area
(cm2)
Oil cap.
(cc)
Closed height
(mm)
Wt. (Approx.)
(kg)
Suitable pump
10 111 10 OLPVL 10-10 15.9 16 30 1.2 OHP-1P4-2-1.5
20 218 10 OLPVL 20-10 31.2 32 35 2.2 OHP-1P4-2-1.5
30 309 10 OLPVL 30-10 44.2 44 40 3 OHP-1P4-2-1.5
50 550 10 OLPVL 50-10 78.5 79 50 6 OHP-1P4-2-1.5
100 1077 10 OLPVL 100-10 153.9 154 70 14 OHP-1P4-2-1.5
150 1589 10 OLPVL 150-10 227 227 75 22 OHP-3P4-2-3
200 2199 10 OLPVL 200-10 314.2 315 80 32 OHP-3P4-2-3

Top Features of Plain Ram Pancake Jacks

1. Built for Harsh Industrial Environments

Built using rugged steel construction, they’re made to take a beating on industrial sites—from refineries and shipyards to bridge installations. Their compact lightweight frame makes transport and setup easier, even in confined pits or under machinery with minimal clearance.

2. Efficient Spring Return Mechanism

One standout detail? The spring return mechanism. This saves time during retraction, especially when working with multiple jacks. Don’t be fooled by the size as many of these units handle high-tonnage capacity ranging from 10 to 200 tons, with lift strokes under 50 mm.

3. Choice Across UAE Industries

That’s exactly why buyers across UAE choose these over standard cylinders, especially when comparing brands like Hi-Force, Enerpac, or SPX PowerTeam. They are made with rugged steel to prevent damage.

Applications of Pancake Jacks in UAE Sectors

. Common Use Cases

One common application is lifting in confined areas, such as beneath transformers or inside turbine housings.

2. Industrial and Heavy Equipment Handling

In oil and gas fields, they’re used for offshore platform maintenance, where low ground clearance and tight decks are typical. Heavy-duty contractors also use them for tank lifting during base repairs or shifting of storage vessels.

3. Machinery Positioning

Their role in machinery positioning is another overlooked strength. It slides under large CNC machines or heat exchangers for micro adjustments.

4. Used Across UAE

Abu Dhabi’s energy corridor and Dubai’s industrial zones are the areas where pancake jacks are known for showing up where space is short but the job demands precision.

Why Orione Hydropower Is UAE’s Trusted Pancake Jack Supplier

1. Stock and Fast Dispatch

Customers looking to buy flat jack UAE appreciate more than just the product. They value Orione’s large local stock in UAE, quick dispatch, and detailed product guidance. Their team doesn’t just ship equipment; they walk clients through specs, tonnage selection, and safe lifting setups.

2. Technical Expertise and Product Guidance

Backed by technical expertise, Orione is known for supplying only premium quality pancake jacks that meet demanding site conditions. With a track record of on-time delivery and long-term client partnerships, they’re often chosen over Hi-Force UAE, Enerpac UAE, and Bemco UAE.

3. Expert Guidance

Got a quick question or unsure which jack fits your project? Orione’s team is just a call away as there are no bots or waiting. There will be just experts who are happy to help. Through sending quotes and helping with shipping, they’re here to make your job easier.

Download Datasheet: Pancake Jacks Plain Ram

Looking for specs before placing an order? Get the Pancake Jack Datasheet UAE and review all the technical details in one go. This hydraulic jack PDF UAE includes stroke lengths, tonnage range, collapsed height, and port positions. It is vital information for planning lifts in restricted spaces. The downloadable spec sheet also features mounting dimensions and materials, making it easier for engineers and buyers to match project needs. The product brochure is ideal for comparison with Enerpac, Hi-Force, and SPX models.

FAQs – Pancake Hydraulic Jack with Plain Ram

How does the jack go back down after lifting?

Many don’t realize that this spring helps reduce wear on seals and fittings by allowing the flat hydraulic jack maintenance to reset naturally. Once you release the hydraulic pressure, the spring automatically pulls the ram back in. It is one of the common Pan jack FAQs UAE.

What’s the best way to store a pancake jack?

Proper storage is one of the most overlooked aspects when it comes to flat jack maintenance UAE. But it can extend your jack’s working life by years. After each job, the ram must be completely retracted to protect the exposed chrome surface from scratches and air contact.

How often do I need to check or service the jack?

A quick look before every use is a good habit. You need to just spot any cracks, leaks, or wear. For regular users, a monthly check-up of the seals, fittings, and body is smart.

What’s the lifting capacity of a pancake jack?

Most pancake jacks you’ll find in the UAE can lift a max load of anywhere between 10 and 200 tons. The exact capacity depends on the model. Always double-check the label on the jack to make sure it matches the weight you're planning to lift.

Can I use a pancake jack sideways?

These jacks are meant for upright use only. If you place them on their side, you risk damaging the inside parts, especially the seals on any cylinder type. Always use them on a flat, stable surface.

Request a Quote – Plain Ram Pancake Jack UAE

Looking to buy pancake jack UAE for a tight-space lifting job? Orione Hydropower offers solid, field-tested jacks built for UAE conditions. Get exact pancake jack price UAE with specs that match your site demands. For genuine models and fast dispatch, contact Orione UAE today to request pricing or a detailed hydraulic jack quote.
