Flat Jacks – Single Acting

In industrial settings with compact and crisp spaces, Flat Jacks Saudi Arabia offers a reliable solution. These are compact lifting tools used for heavy-duty tasks in tight areas. As part of compact hydraulic lifting equipment, they are ideal for multiple tasks. These include lifting, pushing, lowering, and aligning large equipment with ease.

The single acting hydraulic jacks Saudi Arabia are simple yet effective. They work on the hydraulic mechanism, which is great. This makes them easy to use while improving speed and safety on site.

Built with high-strength alloy steel, these jacks resist corrosion and wear. This makes them suitable for extreme heat and dust, common conditions in the Saudi market. You can get these in capacities ranging from 5 to 200 tons. Therefore, these are great for sectors like oil & gas, construction, mining, infrastructure, and shipbuilding.

Moreover, the design of Flat Jacks Saudi Arabia focuses on safety first. One of the primary features is chrome-plated piston rods. Further, there are lock nuts and wiper seals.

There is no doubt that the single acting hydraulic jacks Saudi Arabia are a smart investment. They combine power, precision, and performance. All these assist in supporting critical lifting tasks across various industries. They are a long-term investment with minimal cost.

Flat Jacks – Single Acting Product Overview

Hydraulic Flat Jacks Saudi Arabia are specially designed lifting tools. This is why they perform well in industries where you find space constraints and high load requirements. These are known for their low height and compact build.

The low-height hydraulic cylinders provide reliable performance in tight or limited access areas. Engineering of these focuses on single acting piston. It extends under hydraulic pressure and retracts automatically through a spring return mechanism. This makes them easy to operate and maintain.

These single acting flat jacks Saudi Arabia models offer varied lifting capacities ranging. It starts from 5 to 200 tons and stroke lengths between 8 mm and 16 mm. The spring return system allows for faster retraction, increasing efficiency during repeated use. Further, the high-strength alloy steel and featuring chrome-plated pistons, completes the design. These jacks are corrosion-resistant and rugged, suited for extreme site conditions.

Leading spring return hydraulic jacks come with additional features as well. These include mounting holes for secure placement, wiper seals to prevent contamination, and stacking plates for additional height. Additionally, these are compatible with both hand-operated and electric hydraulic pumps.

Hydraulic Flat Jacks Saudi Arabia saw an increasing demand. It is all because of their performance and quality. They are now working in sectors that need heavy work support. Further applications include aligning large structures, lifting heavy equipment and supporting components in manufacturing units.

Capacity 5 - 200 ton / Stroke 8 - 16 mm / Max. Working pressure 700 bar

Looking for Reliable Flat Jacks in Saudi Arabia?

Get in touch with Orione Hydropower. It is a trusted name for single acting flat jacks Saudi Arabia relies on. Built for performance. Delivered with precision.

Flat Jacks – Single Acting Technical Specifications

Flat Jacks – Single Acting design focuses on precision lifting in tight and confined spaces. These have a compact jack dimension. Further, these tools feature a low-profile hydraulic cylinder and a single-acting piston. It extends with hydraulic pressure and retracts using an internal spring. This design is ideal for fast-paced and repetitive lifting applications. Additionally, if space and speed are critical, these are the best.

Single Acting Jack Technical Details

• Type: Single Acting with Spring Return
• Load Capacity: 5 tons to 200 tons
• Stroke Length: 8 mm to 16 mm
• Closed Height: 35 mm to 115 mm (model dependent)
• Effective Piston Area: 8 cm² to 283.5 cm²
• Oil Capacity: 6 cc to 454 cc
• Maximum Working Pressure: 700 bar

Load Capacity and Stroke Range

These jacks are available in various models. The hydraulic jack load capacity ranges from 5 tons to 200 tons. The stroke length, which determines how far the piston travels, typically ranges from 8 mm to 16 mm. This range allows for a balance of controlled movement and strong lifting force within a small footprint.

Build Material and Surface Treatment

In design, the use of high-strength alloy steel ensures quality. Further, this helps in offering excellent resistance against physical stress and wear. Every unit comes with an anti-corrosive treatment finish. This ensures long-term durability even in harsh outdoor or industrial environments. Now, the piston rod is hard chrome-plated. This reduces friction. It further protects it from moisture, sand, and other contaminants prevalent in the Saudi climate.

Dimensional Specifications

The design focuses on being compact and powerful. These jacks feature compact jack dimensions with closed heights ranging from 35 mm to 115 mm. This enables their use in restricted spaces. Further, this makes them perfect for spaces such as under structural supports or heavy machinery. The effective piston area ranges from 8 cm² to 283.5 cm². This ensures uniform force distribution during operation.

Oil Capacity and Pressure Rating

Every model is different. But each model supports a working pressure of 700 bar tops. Oil capacities range from 6 cc to 454 cc. This further enables smooth piston movement and reliable spring return action. Additionally, the values have a modification facility for ease. This allows for compatibility with both hand-operated and electric hydraulic pumps.

Built for Saudi Industry Standards

Saudi Arabia is a place with a desert and a tough environment. Working with equipment is not easy. These flat jack specifications make it simpler. Their work, performance, and precision are what you need. Further, if you want a tool that supports for long time, these might be the best pick. No matter how the environment changes, these will work with no hassle.

Flat Jacks – Single Acting Features and Benefits

Flat Jacks – Single Acting offers a smart solution for industries. These focus on precision and accomplishment at the same time. If you need compact, powerful, and efficient lifting equipment, these are great.

Further, their low-profile design and rugged construction make them ideal for odd jobs. These work well in tight spaces and harsh environments. Hence, these are best for time-sensitive operations. Let’s explore the key single acting jack features and how they bring value to industrial lifting tasks.

Key Features of Flat Jacks – Single Acting

• Single Acting Operation: The jack extends using hydraulic pressure. This allows for automatic movements that save time.
• Low-Profile Design: These durable hydraulic jacks are compact. Hence, you can use in constraint spaces too.
• High-Strength Body: These are corrosion-resistant. This increases their life. Therefore, they perform better than rest.
• Wiper Seals: No dust accumulation, which increases the lifespan of the tool.
• Mounting Provisions: Includes base and rod-end mounting holes for easier and more stable installation.
• Stacking Plates: You can add stacks to increase the height easily.
• Safety Lock Nut (in few models): It makes load holding simpler, allowing smooth performance.

Advantages of Flat Jacks

• Versatile Applications: This can be used in many industries from construction to manufacturing.
• Time-Saving: The spring mechanism speeds up the work and removes downtime.
• Reliable in Harsh Conditions: The harsh conditions do not impact. Hence, good performance is guaranteed.
• Portable and Easy Usage: You can carry these around easily. Hence, these are great for off-site tasks.

Flat Jacks – Single Acting Applications in Saudi Arabia

Flat Jacks – Single Acting is a trusted solution. These are used in many sectors in Saudi Arabia. Why? Well, because of their strength, reliability, and compact size. The points that make it unique are:

• Low-profile design
• High load capacity
• Ability to function in hot and dusty conditions

1. Oil and Gas Industry

Oilfields and refineries are primary industries in Saudi Arabia. Hence, oil and gas industry lifting equipment is in high demand. They must offer reliable performance under pressure. Flat jacks – single acting are perfect for this. You can use them to lift pipeline components, support valves, and align structural systems. Further, they assist with heavy equipment maintenance. Their work is critical during shutdowns and emergency operations. This makes them so important.

2. Construction and Infrastructure

The construction hydraulic jacks are quite common. These jacks handle lifting tasks in bridge projects, building construction, and roadwork. They help in slab alignment, pre-stressing beams, and positioning heavy equipment within tight structural limits. Saudi Arabia has dense development. This makes these compact jacks perfect and suited to the need.

3. Power and Utilities

The single acting jacks in Saudi industries help with the installation too. It also works well for alignment of turbines, transformers, and switchgear. Their high-pressure tolerance and easy portability. This makes them suitable for both routine maintenance and emergency replacements.

4. Mining and Material Handling

Mining operations benefit from flat jacks greatly. You can use it for lifting large equipment, aligning heavy shafts, and assisting in load transfer tasks. They can operate in rough terrain and dusty conditions. This fits perfectly with Saudi Arabia’s mineral extraction zones.

5. Shipbuilding and Marine Maintenance

At ports and shipyards, hydraulic jacks applications Saudi Arabia are quite useful. These extend to marine tasks such as hull repairs, machinery lifting, and alignment during dry dock servicing. These have a low height and simple design. This makes these tools perfect for such work.

Why Choose Orione Hydropower

Orione Hydropower is the premier high-quality hydraulic equipment producer. It is known for its engineering expertise, durable products, and reliable service. We are a trusted hydraulic jack supplier Saudi Arabia across industries. All because of precision-built lifting tools and customized solutions.

Our Unique Strengths

• Products are made with corrosion-resistant material.
• Available in a range of capacities.
• The quality is maintained at its best.
• There are certifications for all.
• Compatibility for all projects is a checkpoint.
• Perfect for confined and small spaces.
• Our support works 24*7 for you.
• Customization possible as you need.
• We test all our products to ensure performance is not compromised.

Our Commitment to Saudi Arabia

Not every project needs the same tool. If the environment or landscape is tough, you need better solutions. This is why our Saudi Arabia hydraulic solutions are great for you. They have a design that performs well in harsh environments, too. This is why we are trusted by clients across sectors like oil and gas, construction, power, and marine.

If you're searching for a trusted hydraulic jack supplier Saudi Arabia can rely on, choose Orione.

End-to-End Support You Can Rely On

We believe in services that count. As a trusted hydraulic jack supplier Saudi Arabia industries count on us. From after-sales service to customization, we are here to help you. Our experts offer you the solutions you need. This is why we are not just the best, but the most reliable.

Frequently Asked Questions (FAQs)

1. What are Flat Jacks – Single Acting used for?

   Flat jacks are compact hydraulic tools designed to lift, push, or support heavy machinery. These are designed for tight spaces. They work on single-acting spring-return mechanism. This makes them the best for complex industries and hard conditions.

2. What load capacities and stroke ranges are available?

   Flat jacks come in various models. These hydraulic jack load capacities range from 5 tons to 200 tons. The stroke length generally falls between 8 mm and 16 mm. This is why they have so wide application and usage.

3. Can Flat Jacks operate in harsh conditions like those in Saudi Arabia?

   Yes. Flat jacks – single acting are perfect for the harsh conditions of Saudi Arabia. They are made with rugged materials such as alloy steel. This makes them corrosion-resistant. This boosts their performance and allows them to perform better.

4. What type of pumps are compatible with Flat Jacks?

   Flat jacks are available with manual and electric pumps. You can use either of them as you need. The choice is based mainly on the task. Keep speed needs in mind too. It is important that you properly match this to avoid issues or delays.

5. How do I maintain a Flat Jack for long-term use?

   Routine maintenance is important. This includes keeping the jack clean and oiling it regularly. You must also check for any wear or tear. Also, keep them in a safe and secure place. This will ensure a longer lifespan and safe operation.
