General Purpose Jacks - Single Acting

General purpose hydraulic jacks, especially the single acting, have been currently used across multiple industries in Saudi Arabia. In shipbuilding yards and automotive workshops, they take on lifting tasks that most tools can’t handle alone. Their loading capacity, along with their functioning in tough spaces, makes them different.

These versatile hydraulic lifting equipment in Saudi are designed to apply force in one direction (upward). Also, what’s less commonly known is that single acting systems use hydraulic pressure to extend the piston, while a built-in spring brings it back.

Ease of use is another reason for their growing demand. These jacks require minimal setup, have fewer components to maintain, and can be operated by a single technician with basic training. This makes them perfect for both routine and emergency operations, saving time and effort in the field.

Their compact structure and minimal moving parts mean they can be used even in limited spaces without sacrificing performance. Over the years, industries have realized their value not just for lifting but also for pushing, pulling, and pressing operations where controlled force is crucial.

Since these industrial hydraulic jacks from Orione Hydropower don’t require elaborate setup or external power sources for retraction, they’re highly practical for on-site work. As a result, many engineers and technicians prefer keeping them handy. They use them when controlled force is the need of the hour.

General Purpose Jacks Single Acting Overview

Hydraulic general purpose jacks are often overlooked until you’re in a challenging spot. Built for lifting, pushing, and pressing tasks, they have surprising strength in a relatively compact body. One of their standout features is the single acting hydraulic cylinders, which use pressure to push the piston out. It also has a spring to retract it once the job is done.

Most units come with a high-strength alloy steel body that can withstand years of wear. Plus, a chrome-plated piston adds protection against corrosion and surface damage. Because they operate on a single hydraulic input, they’re less complex than double-acting systems.

Another interesting detail is how they behave under high loads. Instead of jerky, uneven motion, these jacks allow a steady and controlled lift. Also, many come with built-in safety rings that prevent over-extension, which is particularly useful when working with unstable or heavy equipment.

As for applications, spring return hydraulic jacks are a go-to in automotive repair, construction, mining, and even shipbuilding. Technicians often use them to lift heavy machinery, align steel structures, or hold components in place during installation.

Besides, their compatibility with standard pumps and accessories saves time when setting up. This also allows professionals to mix and match components without having to replace the entire system.

Finally, high-pressure hydraulic cylinders operate well in compact areas where overhead clearance is a problem. So even though their operation may appear simple on the outside, there’s a lot going on inside that makes these jacks a dependable choice for long-term industrial use.

General Purpose Jacks Single Acting Technical Specifications

When you're dealing with heavy loads and precise lifting, it's good to know what your equipment is truly built for. Our general purpose jack specifications reflect a solid blend of power, structure, and consistency that works across industries.

Technical Specifications

  • Capacity Range: These jacks can handle from 5 tons to a massive 1500 tons, giving you plenty of options depending on your project type.
  • Stroke Length of hydraulic jacks: Stroke lengths start at 50 mm and go up to 200 mm in most models, while OLPS jacks go even higher—ideal when longer lift travel is necessary.
  • Hydraulic jack load capacity: For instance, the OLPS 600-200 model handles a load capacity of 5987 kN, with a massive oil capacity of 17,106 cc.
  • Effective Area: Depending on the model, you’ll find effective areas from 8 cm² in lighter jacks (like OSP 5-50) to 2164.8 cm² in the OLPS 1500 series.
  • Oil Capacity: Ranging from just 40 cc in small models to over 28,000 cc in the OLPS 1000-200 model, you’ll always have enough fluid volume for smooth motion and return.
  • Closed Height and Weight: These jacks are built with compactness in mind, starting from 135 mm and going up to 560 mm in height, depending on capacity and stroke. Weight ranges from as low as 1.3 kg to a hefty 1352 kg for the OLPS 1500-100.

In addition to this, every jack is equipped with chrome-plated rams and a pre-tensioned return spring. This means consistent lifting action and quicker reset times.

Not to mention, all models come with thick-wall construction, so they stand up well to high-pressure environments. While that’s expected in heavy-duty jacks, it's nice to see it executed right.

To sum it up, these single acting jack technical details show just how practical and reliable this range can be. So if you're planning projects with high tonnage or varying strokes, chances are there’s a model in here that fits just right.

Hydraulic Hand Pumps Steel

Capacity 5-1000 ton / Stroke 50-200 mm / Max. Working Pressure 700 bar

Capacity (ton) Capacity (kN) Stroke (mm) Model Effective area (cm2) Oil cap. (cc) Closed height (mm) Wt. (Approx.) (kg)
5 56 50 OSP 5-50 8 40 135 1.3
5 56 100 OSP 5-100 8 80 185 1.8
5 56 150 OSP 5-150 8 121 235 2.3
10 111 50 OSP 10-50 15.9 80 135 2.4
10 111 100 OSP 10-100 15.9 159 185 3.2
10 111 150 OSP 10-150 15.9 239 235 4
10 111 200 OSP 10-200 15.9 318 285 4.7
15 167 50 OSP 15-50 23.8 119 140 4.4
15 167 100 OSP 15-100 23.8 238 190 5.4
15 167 150 OSP 15-150 23.8 356 240 6.4
15 167 200 OSP 15-200 23.8 475 290 7.4
20 218 50 OSP 20-50 31.2 156 145 4.8
20 218 100 OSP 20-100 31.2 312 195 6
20 218 150 OSP 20-150 31.2 468 245 7.4
20 218 200 OSP 20-200 31.2 623 295 8.6
25 270 50 OSP 25-50 38.5 192 155 6.7
25 270 100 OSP 25-100 38.5 385 205 8.4
25 270 150 OSP 25-150 38.5 577 255 10
25 270 200 OSP 25-200 38.5 770 305 11.8
30 309 50 OSP 30-50 44.2 221 160 9
30 309 100 OSP 30-100 44.2 442 210 11.5
30 309 150 OSP 30-150 44.2 663 260 13.5
30 309 200 OSP 30-200 44.2 884 310 15.5
50 550 50 OSP 50-50 78.5 393 175 15.5
50 550 100 OSP 50-100 78.5 785 225 19
50 550 150 OSP 50-150 78.5 1178 275 22.5
50 550 200 OSP 50-200 78.5 1571 325 26.5
75 792 50 OSP 75-50 113.1 565 180 22
75 792 100 OSP 75-100 113.1 1131 230 27
75 792 150 OSP 75-150 113.1 1696 280 33
75 792 200 OSP 75-200 113.1 2262 330 38
100 1077 50 OSP 100-50 153.9 770 185 30
100 1077 100 OSP 100-100 153.9 1539 235 37.5
100 1077 150 OSP 100-150 153.9 2309 285 44.5
100 1077 200 OSP 100-200 153.9 3079 335 52
150 1589 50 OSP 150-50 227 1135 200 54
150 1589 100 OSP 150-100 227 2270 250 65
150 1589 150 OSP 150-150 227 3405 300 76
200 2199 50 OSP 200-50 314.2 1571 215 71
200 2199 100 OSP 200-100 314.2 3142 265 86.5
200 2199 150 OSP 200-150 314.2 4712 315 102
250 2661 100 OSP 250-100 380.1 3801 270 109
250 2661 150 OSP 250-150 380.1 5702 320 126
250 2661 200 OSP 250-200 380.1 7603 370 143
300 3167 100 OSP 300-100 452.4 4524 285 141
300 3167 150 OSP 300-150 452.4 6786 335 164
300 3167 200 OSP 300-200 452.4 9048 385 187
400 4008 100 OSP 400-100 572.6 5726 315 190
400 4008 150 OSP 400-150 572.6 8588 365 217
400 4008 200 OSP 400-200 572.6 11451 415 243
Capacity
(ton)		 Capacity
(kN)		 Stroke
(mm)		 Model Effective area
(cm2)		 Oil cap.
(cc)		 Closed height
(mm)		 Wt. (Approx.)
(kg)
10 111 50 OSPS 10-50 15.9 80 145 2.6
10 111 100 OSPS 10-100 15.9 159 195 3.4
10 111 150 OSPS 10-150 15.9 239 245 4.2
10 111 200 OSPS 10-200 15.9 318 295 4.9
15 167 50 OSPS 15-50 23.8 119 155 4.6
15 167 100 OSPS 15-100 23.8 238 205 5.6
15 167 150 OSPS 15-150 23.8 356 255 6.6
15 167 200 OSPS 15-200 23.8 475 305 7.6
20 218 50 OSPS 20-50 31.2 156 160 5.1
20 218 100 OSPS 20-100 31.2 312 210 6.3
20 218 150 OSPS 20-150 31.2 468 260 7.7
20 218 200 OSPS 20-200 31.2 623 310 8.9
25 270 50 OSPS 25-50 38.5 192 170 7
25 270 100 OSPS 25-100 38.5 385 220 8.7
25 270 150 OSPS 25-150 38.5 577 270 10.3
25 270 200 OSPS 25-200 38.5 770 320 12.1
30 309 50 OSPS 30-50 44.2 221 175 9.4
30 309 100 OSPS 30-100 44.2 442 225 11.9
30 309 150 OSPS 30-150 44.2 663 275 13.9
30 309 200 OSPS 30-200 44.2 884 325 15.9
50 550 50 OSPS 50-50 78.5 393 190 16
50 550 100 OSPS 50-100 78.5 785 240 19.5
50 550 150 OSPS 50-150 78.5 1178 290 23
50 550 200 OSPS 50-200 78.5 1571 340 27
75 792 50 OSPS 75-50 113.1 565 205 22.9
75 792 100 OSPS 75-100 113.1 1131 255 27.9
75 792 150 OSPS 75-150 113.1 1696 305 33.9
75 792 200 OSPS 75-200 113.1 2262 355 38.9
100 1077 50 OSPS 100-50 153.9 770 205 31
100 1077 100 OSPS 100-100 153.9 1539 255 38.5
100 1077 150 OSPS 100-150 153.9 2309 305 45.5
100 1077 200 OSPS 100-200 153.9 3079 355 53
150 1589 50 OSPS 150-50 227 1135 225 56
150 1589 100 OSPS 150-100 227 2270 275 67
150 1589 150 OSPS 150-150 227 3405 325 78
200 2199 50 OSPS 200-50 314.2 1571 240 74.5
200 2199 100 OSPS 200-100 314.2 3142 290 90
200 2199 150 OSPS 200-150 314.2 4712 340 105.5
250 2661 100 OSPS 250-100 380.1 3801 305 114
250 2661 150 OSPS 250-150 380.1 5702 355 131
250 2661 200 OSPS 250-200 380.1 7603 405 148
300 3167 100 OSPS 300-100 452.4 4524 320 148
300 3167 150 OSPS 300-150 452.4 6786 370 171
300 3167 200 OSPS 300-200 452.4 9048 420 194
400 4008 100 OSPS 400-100 572.6 5726 355 201
400 4008 150 OSPS 400-150 572.6 8588 405 228
400 4008 200 OSPS 400-200 572.6 11451 455 254
500 4948 100 OSPS 500-100 706.9 7069 365 270
500 4948 150 OSPS 500-150 706.9 10603 415 306
500 4948 200 OSPS 500-200 706.9 14137 465 343
Capacity
(ton)		 Capacity
(kN)		 Stroke
(mm)		 Model Effective area
(cm2)		 Oil cap.
(cc)		 Closed height
(mm)		 Wt. (Approx.)
(kg)
600 5987 100 OLPS 600-100 855.3 8553 390 357
600 5987 150 OLPS 600-150 855.3 12829 440 404
600 5987 200 OLPS 600-200 855.3 17106 490 450
800 7939 100 OLPS 800-100 1134.1 11341 425 525
800 7939 150 OLPS 800-150 1134.1 17012 475 590
800 7939 200 OLPS 800-200 1134.1 22682 525 654
1000 9930 100 OLPS 1000-100 1418.6 14186 460 721
1000 9930 150 OLPS 1000-150 1418.6 21279 510 800
1000 9930 200 OLPS 1000-200 1418.6 28373 560 879
1500 15154 100 OLPS 1500-100 2164.8 21648 545 1352
1500 15154 150 OLPS 1500-150 2164.8 32472 595 1482
1500 15154 200 OLPS 1500-200 2164.8 43296 645 1612
2000 20458 100 OLPS 2000-100 2922.5 29225 615 2023
2000 20458 150 OLPS 2000-150 2922.5 43837 665 2195
2000 20458 200 OLPS 2000-200 2922.5 58450 715 2367

General Purpose Jacks Single Acting Technical Specifications

When you're dealing with heavy loads and precise lifting, it's good to know what your equipment is truly built for. Our general purpose jack specifications reflect a solid blend of power, structure, and consistency that works across industries.

Technical Specifications

  • Capacity Range: These jacks can handle from 5 tons to a massive 1500 tons, giving you plenty of options depending on your project type.
  • Stroke Length of hydraulic jacks: Stroke lengths start at 50 mm and go up to 200 mm in most models, while OLPS jacks go even higher—ideal when longer lift travel is necessary.
  • Hydraulic jack load capacity: For instance, the OLPS 600-200 model handles a load capacity of 5987 kN, with a massive oil capacity of 17,106 cc.
  • Effective Area: Depending on the model, you’ll find effective areas from 8 cm² in lighter jacks (like OSP 5-50) to 2164.8 cm² in the OLPS 1500 series.
  • Oil Capacity: Ranging from just 40 cc in small models to over 28,000 cc in the OLPS 1000-200 model, you’ll always have enough fluid volume for smooth motion and return.
  • Closed Height and Weight: These jacks are built with compactness in mind, starting from 135 mm and going up to 560 mm in height, depending on capacity and stroke. Weight ranges from as low as 1.3 kg to a hefty 1352 kg for the OLPS 1500-100.

In addition to this, every jack is equipped with chrome-plated rams and a pre-tensioned return spring. This means consistent lifting action and quicker reset times.

Not to mention, all models come with thick-wall construction, so they stand up well to high-pressure environments. While that’s expected in heavy-duty jacks, it's nice to see it executed right.

To sum it up, these single acting jack technical details show just how practical and reliable this range can be. So if you're planning projects with high tonnage or varying strokes, chances are there’s a model in here that fits just right.

General Purpose Jacks Single Acting Features and Benefits

If you’re looking for a reliable lifting solution in Saudi Arabia, durable hydraulic jacks are a great pick. They offer an amazing strength and make them easy to use in tough work environments. If it’s for workshops or heavy-duty tasks, these jacks will be able to get the job done easily.

Key advantages of general purpose jacks

  • Side-load can really wear down a jack fast. But because of a solid bearing system and tough composite wear bands, these jacks can take pressure from all directions.
  • And when it comes to durability, the high-grade polyethylene seals are one of the best single acting jack features. It helps cut down wear and tear, making sure your jack lasts longer without frequent replacements.
  • They are supported by a plunger wiper that prevents dirt and debris from compromising the system’s internal components.
  • Most models come with collar and plunger threads, plus base mounting holes. This allows for easier fixturing without requiring any additional modifications.
  • Every jack includes a CR400 coupler, dust cap, and collar thread protector right out of the box, so you're not left searching for compatible accessories.
  • Cylinders over 25 kg are also fitted with certified lifting eyes for safer handling. Additionally, they’re interchangeable with the optional CHM6 carrying handle.
  • To prevent corrosion, each jack has a baked enamel finish and such small details add extra resilience. It especially functions in harsher work settings.
  • If you’ve worked with previous RC-Series jacks, you’ll appreciate that these models maintain the same external dimensions and threads.
  • If you’re in Saudi Arabia and need efficient lifting equipment, they’re a solid choice. They work well under pressure, are easy to set up, and don’t demand much upkeep.

So, if you're looking to keep things running easier in your shop or out in the field, the advantages of general purpose jacks are hard to miss.

General Purpose Jacks Single Acting Applications Across Industries

Single acting jacks are the best lifting tools that a lot of industries are using. Their operation, durable build, and ability to function in multiple positions make them a practical choice in both routine and demanding tasks.

Here’s are the common hydraulic jacks applications:

  1. Construction: Automotive lifting equipment can be used for heavy things like beams, machines, or big building parts. When it’s time to put structures together or shift bulky materials, these jacks handle the load.
  2. Material Handling: Get the construction hydraulic jacks that can work in warehouses for lifting and shifting heavy pallets, molds, or bulky equipment. These jacks can take the heavy work of lifting off your shoulders. Just a few pumps, and you will be ready to reposition everything in the way.
  3. Rail and Transportation: Next up is the rail and transport industry. If you are working on railcars, you can get jacks to get the alignment right. They are the perfect choice for this because of their good consistency. Also, single acting jacks will help in keeping rail systems running.
  4. Agriculture: On farms, everyday tasks such as adjusting tractor attachments or heavy tools will become much simpler with jacks. Additionally, the single acting jacks will help farmers lift to the right height without wasting a lot of energy on this hard work.
  5. Marine: In shipyards or dry docks, handling various components is part of the job. However, with these jacks, technicians can position parts with better control and less strain. That means there will be fewer delays during construction or repair work.
  6. Aerospace: Similarly, these jacks work for aerospace teams as it becomes an easy task for them to assemble aircraft and do their maintenance. These tools will help engineers to move parts and support during procedures that are delicate.

Moreover, with the growing industrial base in Saudi Arabia, there’s a rising demand for single acting jacks in industries like these.

Why Choose Orione Hydropower

At Orione Hydropower, a trusted hydraulic jack supplier, we provide you with the long-lasting jacks that can be used across industrial and commercial sectors. With capacities ranging from 10 to 500 tons, our range of general-purpose hydraulic jacks and cylinders is built to handle a variety of applications including lifting, pushing, pulling, and holding.

Here’s what sets us apart:

  • Broad Product Range: From single to double acting jacks, plain rams to threaded rams with safety lock nuts, we provide a large selection to match different operational requirements.
  • Custom-Built for You: As a reliable general purpose jacks manufacturer, we understand that one-size-fits-all doesn't always apply. That's why we offer customized hydraulic solutions even if it is special designs, spring return, load return, or mounting accessories.
  • Built to Last: We know a good jack is about how long it holds up under pressure. Our jacks feature hard chrome-plated pistons, solid wiper seals, and strong springs that snap back into position without dragging. Plus, with handy carrying handles or eye bolts, moving them around isn’t a struggle.
  • Complete Kits Available: Need a full kit? We offer complete setups like hand pumps, power packs, high-pressure hoses, pressure gauges, and quick couplers. You need to just plug, pump, and power up.
  • Used Across Industries: From shipyards to power plants, and defense to mining, our high-quality hydraulic equipment is out there doing real work. Companies in the infrastructure, cement, and chemical sectors count on us for strength.

Frequently Asked Questions (FAQs)

  1. Can I use your single acting jacks in Saudi Arabia’s climate?
    Yes. It will be possible for you to use single acting jacks in high-heat zones of Saudi Arabia. In intense heat and dry conditions, these jacks are capable of maintaining smooth piston action. Even if there's quick wear or leakage, these jacks will in a great way prevent it in the future.
  2. What is a single acting hydraulic jack and how does it work?
    A single acting jack uses pressurized fluid to push the piston out, and then a spring (or the load itself) brings it back. Also, since it has just one hydraulic port, setting it up is fast and simple. It’s especially easy to handle in tight corners or compact spaces where other tools might not fit.
  3. What safety features do your single acting jacks include?
    Each jack comes with a pressure relief valve and a safety lock nut option, depending on the model. Additionally, hard chrome-plated pistons and strong wiper seals help maintain performance while reducing maintenance. This gives users added confidence during heavy-duty tasks.
  4. Do you export general purpose jacks to Saudi Arabia and other countries?
    Yes, we supply our single acting jacks to clients across India and regularly ship orders to Saudi Arabia and nearby regions. Thanks to our consistent build standards, clients often choose us for repeat orders and long-term use in infrastructure and industrial settings abroad.
  5. How do I choose the right jack for my application?
    Start by figuring out three simple things: how heavy the load is, how high you need to lift it, and space you’ve got to work with. Next, think about how you’d like the jack to return. If you're not sure which setup fits best, we're always here to walk you through the options and suggest what’ll work best for your exact situation.
Request A Quote Hydraulic Hand Pumps Steel
Pancake Jacks Threaded Ram

General Purpose Jacks Single Acting

General Purpose Jacks Single Acting

Pancake Jacks Threaded Ram

General Purpose Jacks Single Acting

General Purpose Jacks Single Acting

Pancake Jacks Threaded Ram

Low Height Jacks Single Acting

Low Height Jacks Single Acting

Hydraulic Jacks
Hydraulic Jack Accessories
Hydraulic tank jacking equipment
Hydraulic Hand Pumps Steel
Hydraulic Power Packs
Hydraulic Torque Wrench
Special Hydraulic Tools
Equipment For Construction & Infrastructure Industries
Hydraulic Presses
Hydraulic Cylinders
Customised Hydraulic Power Packs
Rental Of Hydraulic Tools
Tailor Made Solutions
Car Stack Parking

Related Products

Hydraulic Jacks

Hydraulic Jacks

Hydraulic jacks are beneficial mechanical devices. They are designed to lift heavy objects with minimal effort. Hydraulic jacks are employed in the automotive and construction industries. These jacks use hydraulics to provide a higher lift capacity over longer distances. Hydraulic jacks are used in Railways, railroad defense, earthmoving equipment, aeronautical, mining, lifting platforms, hydropower facilities, and defense equipment.

Orione Hydropower provides various industrial hydraulic jacks perfect for any of these applications. We offer Jacks for light and heavy duties. Our hydraulic jacks are made of high-quality material to provide long life and meet your standards. We are the best Hydraulic Jacks Manufacturers in Navi Mumbai, Maharashtra, India. We offer Hydraulic Jacks to our clients at a low price.

Read More

Hydraulic Hand Pumps

Hydraulic Hand Pumps

A Hydraulic Hand Pump is a tool consisting of a cylinder and a piston and is used in various construction and heavy industrial applications. These hand-operated machines transform mechanical energy into hydraulic energy by applying pressure to allow for the smooth flow of liquids.

Orione Hydropower, a market-leading Hydraulic Hand Pump Manufacturer in Navi Mumbai,India, is at the forefront of producing the finest Hydraulic jack, Hydraulic Hand Pumps, and other products. For long-term usage, the products are made of high-quality Steel. Our hydraulic hand pumps are divided into two types: single-acting pumps and dual-acting pumps.

Read More

Hydraulic Power Packs

Hydraulic Power Packs

Hydraulic power devices have recently become an essential technology for many modern companies seeking to improve production efficiency. A self-contained power unit is a hydraulic power pack. A reservoir or tank hydraulic pump, a motor, gauges, and valves are all part of it. The device transfers power between two sites and provides the pressure needed to drive a hydraulic machine.

Hydraulic power packs are commonly used in a variety of industrial applications, such as manufacturing, construction, and material handling. They can provide power to hydraulic cylinders, motors, and other components, allowing machines to perform tasks such as lifting heavy loads, bending metal, and drilling through hard materials.

Read More

Hydraulic Torque Wrench

Hydraulic Torque Wrench

Hydraulic torque wrenches are professional tools used to tighten fasteners of different sizes in a controlled way for industrial applications. It is a portable torque wrench that has been improved. A hydraulic torque wrench is an electric tool that uses hydraulics to give a fastener the right amount of torque to tighten or loosen it.

Hydraulic torque wrenches are smaller and quieter than pneumatic torque wrenches. They are also lighter. These wrenches are accurate to 3% and will last a long time. They are also used in industries and situations where large bolts need to be tightened to a precise level.

Read More

Hydraulic Pullers

Hydraulic Pullers

A hydraulic puller removes shaft components such as bearings, pulleys, and gears. Hydraulic pullers usually have two or three legs that go around the part that needs to be removed and a forcing screw that centers up against the end of a shaft. These pullers work well because they use controlled hydraulic forces to separate parts quickly, especially compared to manual methods. When appropriately used, hydraulic pullers don't damage any parts for maintenance, which can be important when time is of the essence.

Orione Hydropower is a leading manufacturer and supplier of Hydraulic Hydraulic Puller in Navi Mumbai, Maharashtra, India. Our high-end designs are made of metal to prevent corrosion and withstand wear. As a trusted manufacturer in Navi Mumbai, we use only the finest quality materials to deliver the best options to our customers. Please browse our website and place your order according to your preferences.

Read More

Monostrand Hollow Ram Jacks

Monostrand Hollow Ram Jacks

Monostrand hollow ram jacks are hydraulic jacks designed for applications involving pre-stressing and post-tensioning of concrete structures. They also pull and lock high-tensile threaded bars in construction projects.

Monostrand hollow ram jacks are essential for achieving optimal strength, durability, and performance in concrete structures. They are easy to use, safe, and reliable. They can help you save time, money, and resources in your construction projects.

Orione Hydropower is a leading manufacturer and supplier of Monostrand Hollow Ram Jacks in Navi Mumbai, Maharashtra, India. Our high-end designs are made of metal to prevent corrosion and withstand wear. As a trusted manufacturer in Navi Mumbai, we use only the finest quality materials to deliver the best options to our customers. Please browse our website and place your order according to your preferences.

Read More

Hydraulic Cylinders

Hydraulic Cylinders

It is essential first to understand the customer's needs. Then need to know about the working application, usage, working stroke, acting load, working environment, and repeatability of working. And many working cycles by which we can assist in choosing the right type of cylinders used, such as mounting type, operating pressure, types of seals to incorporate to give the cylinders maximum life, and selection of materials in making the hydraulic cylinders. Early collaboration saves the engineering teams cash and time while ensuring the final system performs its allocated responsibilities as effectively as feasible for as long as possible.

We have designed several models to meet our customer's demands, who expect to look to us for hydraulic solutions. We are the best Hydraulic Cylinders Manufacturers in Navi Mumbai, Maharashtra, India. We offer Hydraulic Cylinders to our clients at a low price. Please browse our website and place your order according to your preferences.

Read More

Hydraulic Presses

Hydraulic Presses

Hydraulic Press is always in high demand across many sectors. They enable users to fit, assemble and bend sheet metals, bearings, and other machine parts. Hydraulic presses use pump-generated pressure to compress steel cylinders into metals.

A hydraulic press is a mechanical machine that shapes and deforms metals by transferring energy through the liquid. It is based on Pascal's principle. The gadget is primarily used to increase the application of lesser forces. According to Pascal's guide, pressure strength in a static fluid is transferred equally in all directions.

Orione Hydropower is a leading manufacturer and supplier of Hydraulic Press in Navi Mumbai, Maharashtra, India. Our high-end designs are made of metal to prevent corrosion and withstand wear. As a trusted manufacturer in Navi Mumbai, we use only the finest quality materials to deliver the best options to our customers. Please browse our website and place your order according to your preferences.

Read More

Hydraulic Tank Jack

Hydraulic Tank Jack

A hydraulic tank jack is used to lift and erect storage tanks of different sizes and shapes. It is also known as a hydraulic tank jacking system or tank lift jack. Hydraulic tank jack can be used for welded and bolted tanks, offering many advantages over conventional tank construction methods

Hydraulic tank jacks have two main parts: a hydraulic pump and a set of jacking units. The hydraulic pump provides pressurized fluid to the jacking units, which are attached to the tank or cylinder at different points. The jacking units consist of a piston and a cylinder that can extend or retract depending on the direction of fluid flow; by synchronizing the movement of multiple jacking units, the tank or cylinder can be lifted or lowered with precision and safety.

Orione Hydropower is a leading manufacturer and supplier of Hydraulic Tank Jack in Navi Mumbai, Maharashtra, India. Our high-end designs are made of metal to prevent corrosion and withstand wear. As a trusted manufacturer in Navi Mumbai, we use only the finest quality materials to deliver the best options to our customers. Please browse our website and place your order according to your preferences.

Read More

Pancake Jacks Plain Ram

Pancake Jacks Plain Ram

Pancake jacks plain ram are a type of hydraulic jacks with a compact, flat design and a single-acting, load-return mechanism. They are also known as hydraulic flat jacks or low-profile jacks. They have the plain ram with no threads or attachments on them. The ram is made of heat-treated alloy steel and hard chrome plated to resist corrosion and wear.

Pancake jacks plain ram are used for various applications that require lifting, aligning, pushing, or pulling heavy loads in confined spaces with shallow clearance. They are ideal for the precision lifting and alignment of machinery, heavy structures, bridges, pipelines, vessels, and equipment. They can also remove pulleys, sprockets, gears, and bearings on taper seats.

Orione Hydropower is a leading manufacturer and supplier of Pancake Jacks Plain Ram in Navi Mumbai, Maharashtra, India. Our high-end designs are made of metal to prevent corrosion and withstand wear. As a trusted manufacturer in Navi Mumbai, we use only the finest quality materials to deliver the best options to our customers. Please browse our website and place your order according to your preferences.

Read More

Pancake Jacks Threaded Ram

Pancake Jacks Threaded Ram

Pancake Jacks Threaded Ram are a type of hydraulic jack with a shallow height and a threaded ram that can be locked with a nut for safety. They are used for lifting, lowering, spreading, or aligning heavy structures, machinery, bridges, or pulleys in confined spaces where no other cylinders will fit.

Pancake jacks with threaded ram are versatile tools that can handle various lifting tasks in tight spaces. Pancake jacks threaded ram are easy to operate and maintain. They offer high performance, safety, and reliability at an affordable price.

Orione Hydropower is a leading manufacturer and supplier of Pancake Jacks Threaded Ram in Navi Mumbai, Maharashtra, India. Our high-end designs are made of metal to prevent corrosion and withstand wear. As a trusted manufacturer in Navi Mumbai, we use only the finest quality materials to deliver the best options to our customers. Please browse our website and place your order according to your preferences.

Read More

Flat Jacks Single Acting

Flat Jacks Single Acting

Flat jacks single-acting are hydraulic jacks with a compact and flat design, making them ideal for applications with limited insertion space. They have a spring return mechanism that retracts the piston after the pressure is released. They are utilized for different purposes, such as pushing, raising, separating, lowering, aligning, and clamping heavy objects.

Flat jacks single acting come in different capacities ranging from 5 tons to 200 tons and strokes ranging from 8 mm to 16 mm. They have a maximum working pressure of 700 bar and can be operated with a hand pump or an electric pump. Some models also have mounting holes for easy fixturing and stacking plates for increasing the closed height.

Orione Hydropower is a leading manufacturer and supplier of Flat Jacks Single Acting in Navi Mumbai, Maharashtra, India. Our high-end designs are made of metal to prevent corrosion and withstand wear. As a trusted manufacturer in Navi Mumbai, we use only the finest quality materials to deliver the best options to our customers. Please browse our website and place your order according to your preferences.

Read More

Low Height Jacks Single Acting

Low Height Jacks Single Acting

Low height jacks single acting are hydraulic jacks with a plain ram and a spring return mechanism. They are designed for use in confined areas where space is limited. Depending on the capacity, they can lift heavy loads with a short stroke of 8 to 60 mm. The accommodation ranges from 5 to 200 tons, and the maximum working pressure is 700 bar.

Low height jacks single acting are used in various industries such as power and steel plants, shipbuilding and repair, and construction. They have mounting holes for easy fixing and comply with ASME B30.1 standards (except BRD-RD-Series).

Orione Hydropower is a leading manufacturer and supplier of Low Height Jacks Single Acting in Navi Mumbai, Maharashtra, India. Our high-end designs are made of metal to prevent corrosion and withstand wear. As a trusted manufacturer in Navi Mumbai, we use only the finest quality materials to deliver the best options to our customers. Please browse our website and place your order according to your preferences.

Read More

General Purpose Jacks Threaded Ram

General Purpose Jacks Threaded Ram

Hydraulic jacks use pressurized fluid to lift or push heavy objects. They are widely utilized in different industries such as construction, mining, engineering, automotive, etc. Hydraulic jacks come in different types, sizes, and capacities depending on the application and the load requirements.

General purpose jacks threaded ram is usually single acting, which means they have one hydraulic port and rely on a spring to retract the ram when the pressure is released. They can also be double acting, which means they have two hydraulic ports and can extend and retract the ram by applying pressure alternately.

Orione Hydropower is a leading manufacturer and supplier of General Purpose Jacks Threaded Ram in Navi Mumbai, Maharashtra, India. Our high-end designs are made of metal to prevent corrosion and withstand wear. As a trusted manufacturer in Navi Mumbai, we use only the finest quality materials to deliver the best options to our customers. Please browse our website and place your order according to your preferences.

Read More

General Purpose Jacks Double Acting

General Purpose Jacks Double Acting

General purpose jacks are hydraulic devices that can be used for lifting, pushing, pulling, or holding loads in various applications. They consist of a cylinder, a piston, a pump, and a valve that controls the flow of hydraulic fluid. Double-acting jacks have two ports for fluid inlet and outlet, which allow them to extend and retract the piston with hydraulic pressure.

General purpose jacks double acting are robust and reliable tools that can help you with various tasks involving lifting or moving heavy objects. However, you should always follow the manufacturer's instructions and safety precautions when using them.

Orione Hydropower is a leading manufacturer and supplier of General Purpose Jacks Double Acting in Navi Mumbai, Maharashtra, India. Our high-end designs are made of metal to prevent corrosion and withstand wear. As a trusted manufacturer in Navi Mumbai, we use only the finest quality materials to deliver the best options to our customers. Please browse our website and place your order according to your preferences.

Read More

General Purpose Threaded Ram Double acting

General Purpose Threaded Ram Double acting

Lorem ipsum dolor sit amet consectetur adipisicing elit. Accusamus a neque nesciunt voluptate dolor? Quos blanditiis aperiam totam explicabo natus, aut ad veniam inventore mollitia laborum libero harum sequi nostrum! Lorem ipsum dolor sit amet consectetur adipisicing elit. Accusamus a neque nesciunt voluptate dolor? Quos blanditiis aperiam totam explicabo natus, aut ad veniam inventore mollitia laborum libero harum sequi nostrum!

Read More

Hollow Ram Jacks Single Acting

Hollow Ram Jacks Single Acting

Hollow ram jacks are hydraulic cylinders with holes in the center of the piston and rod. They are used for applications that require pulling and pushing forces, such as tensioning, testing, stressing, or lifting loads with a threaded rod.

Single acting hollow ram jacks are more superficial and lighter than double acting ones, which require hydraulic pressure for both extension and retraction.

Orione Hydropower is a leading manufacturer and supplier of Hollow Ram Jacks Single Acting in Navi Mumbai, Maharashtra, India. Our high-end designs are made of metal to prevent corrosion and withstand wear. As a trusted manufacturer in Navi Mumbai, we use only the finest quality materials to deliver the best options to our customers. Please browse our website and place your order according to your preferences.

Read More

Hollow Ram Jacks Double Acting

Hollow Ram Jacks Double Acting

Hollow ram jacks double acting are hydraulic cylinders with a hollow plunger that allows push and pull forces. They are used for various applications such as tensioning, testing, lifting, pushing, pulling, bending, or holding. They can also be used with accessories such as threaded adapters, swivel caps, clevis eyes, or spherical saddles to suit different needs.

Hollow ram jacks double acting have some advantages over single acting ones. They have a faster and more precise retraction due to the hydraulic pressure on both sides of the plunger. They also have a longer stroke length and can operate in any position. However, they also require hydraulic fluid and a four-way valve to control the flow direction.

Orione Hydropower is a leading manufacturer and supplier of Hollow Ram Jacks Double Acting in Navi Mumbai, Maharashtra, India. Our high-end designs are made of metal to prevent corrosion and withstand wear. As a trusted manufacturer in Navi Mumbai, we use only the finest quality materials to deliver the best options to our customers. Please browse our website and place your order according to your preferences.

Read More
Request A Quote
Whatsapp
Phone
Enquiry
